Quinton Hazell QJB100T CV Boot Tool

Safety information

Safety First Read the operating and safety instruction. Follow them carefully. Maximum safe operating pressure 9 bar (125 psi). Air lines are dangerous - use them correctly Putting into service Before use check cap-retaining screws are secure.If the Air tool is dropped check for cracked components. Check air line pressure before connecting the Air tool.The Air tool should be used only by people trained in the use of pneumatically operated tools. Use Keep hands away from moving parts. Never operate the Air tool near the face or body. Only use Air tool to fit CV boots. If air line pressure exceeds 9 bar fit a regulator. Disconnect the Air tool from the air supply after use.

Installation Information

Operation: 1. Slide boot onto arms, large end first. The arms should just protrude from the small end of the boot. To fit a boot to an inner joint, turn the boot inside out before sliding i onto the Airtools´s arm. 2. Press " + " button until arms open enough to pass over the joint. Keep hands clear of moving parts. The air line can now be disconnected. The arms will remain open until the " - " button is pressed. 3. Place Airtool over CV joint and press release button (" -"). Keep hands away from moving parts. 4. Withdraw the Airtool, leaving the boot in position. Complete the installation in the normal way.
