Results 1 - 12 of 12
Part number: 0684010050
Important compatibility info
| Depth | 50 mm |
| Temperature range | -20 - 55 °C |
| Temperature range from | -20 °C |
| Temperature range to | 55 °C |
| Extra Description | FSA 050 |
Additional Information
The FSA 050 high-voltage multimeter tests all electrical drive systems and is the fast and convenient way to competently troubleshoot faults with electric and hybrid vehicles. With the handy FSA 050 in your workshop, you’ll be up-to-date and prepared for the trend towards electrical drives.
- Standalone tester: Get fast results with insulation and high-voltage testing for electric and hybrid drive
- Combines as a test module with FSA 500: Enhance functionality and output to comprehensively document measurement test results
- Compact (220 x 110 x 65 mm): Handy size for efficient working
- Lightweight (0.8 kg): The mobile solution around the workshop
- Bluetooth interface: Ultimate convenience – wirelessly transmit test results to workshop PC or FSA series
- Complete with storage case, two measuring cables, high-voltage probe, CD/DVD CompacSoft[plus] and Bluetooth USB stick: It’s the economical package for testing electrical drive systems
- Wireless connectivity: Conntect with Bosch Connected Repair or other workshop networks to help you work more efficiently
- High-voltage analysis: up to 600 V (TRMS)
- Insulation analysis:until 200 G Ω
- Insulation resistance: 50 - 100 - 250 - 500 - 1 000 V
- Test voltages: 1 mA
- Test current Measurement modes: t, PI, DAR
- Resistance measurement: 0.01 - 1 000 kOhm
- Continuity testing: 0.01 - 99.9 Ohm with test current 20 mA / 205 mA
- Capacitance measurement: 100 picofarad - 10 microfarad
- Data transmission: Bluetooth class I (up to 30 m range)
- Power supply: Batteries 5x IEC LR6 (AA)
- Operating temperature range -20 - 55 degree(C)
- Weight: 0.8 kg
- Dimensions: 220 x 92 x 50 mm
ONLY
£1,358.58
£1,358.58
Part number: 0687000044
Important compatibility info
Additional Information
The Bosch BAT 6120 is a future-proof, professional, two-in-one battery support solution for automotive workshops. Functioning dependably as a smart and fast battery charger, for lead acid and lithium batteries, or as a 120 A continuous power supply.
- Supports 120 A DC Continuous Output (AC120 V - 240 V, 25 degree Celcius)
- Supports Flooded/AGM/EFB/GEL/Lithium (LFP) Batteries
- 12 V Lead Acid Battery Charge. Charging Diagnosis / 12 V Lithium Battery Charge, Wake Up
- Interface available in 26 languages
- Maximum power output: up to 1750 W
- Flexible operation modes to fulfill customer needs
- Desk, floor or wall operations possible
- Fits underneath a car in show room
- Easy to use large 4 colour backlight LCD display including wall mount mode
- Easy access to BAT 6120 Help Center web page through QR code displayed on the screen
- Max. Charge current intensity 12V: 120 A
- Length of the charging cable: 3 m (twin cable)
- Cross-section charging cable: 25 mm sq.
- Power input :120 - 240 V AC
- Weight (without charging and power cable): 8.5 kg
- Charging characteristic: up to 120 Amperes continuous. Battery types: UNI, WET, EFB, AGM, VRLA/GEL, LFP (LiFePO4)
- Backup mode: 12.0 V - 13.2 V adjustable, default 12.6 V / 10 A - 30 A adjustable power limit, default 20 A
- Floating-mode operation: 12.0 V - 13.2 V adjustable, default 13.5 V
- Max. 120 A continuous current
- Function temperature range: 0 – 40 degree(C)
- Main voltage: 220 - 240 V, 50/60 Hz
- Battery nominal voltage: 12 V
- Protection type (DIN 40050): IP 20 D
- Dimensions (W x H x D): 329 x 116 x 433 mm
ONLY
£1,162.76
£1,162.76
Part number: 0684400253
Important compatibility info
| Title | Bosch TPA 300 - Programming Tool for TPMS |
Additional Information
The TPA 300 has been specially developed for the vehicle-specific configuration of universal sensors for tire pressure monitoring systems (TPMS). It achieves a vehicle coverage of over 95%. Over 20 different universal sensor brands can be programmed for very high market coverage. Through wireless transmission, the TPMS data is displayed and checked directly on the color 2.8” display. The quick and easy operation of the programming tool enables uncomplicated sensor programming and vehicle relearning procedures. Regular software updates of functions, vehicles and sensor coverage ensure that workshops are up-to-date and can serve their customers accurately.
- Vehicle coverage of over 95%
- Reading & cloning of wide range of OE-sensors
- Programming a broad range of universal sensors
- Relearn procedures for many of vehicles
- Intuitive, full-color display with easy vehicle lookup by make, model and year
- Supports the majority of OE and aftermarket programmable sensors for passenger car and LCV vehicles
- New features, vehicles and sensor coverage added regularly
- Approximately 300 activations per full charge
- Includes 3 years of free software updates
ONLY
£598.48
£598.48
Part number: 0687000115
Important compatibility info
Additional Information
Offering a wide-range of testing norms, such as EN, EN2, DIN, SAE, IEC, JIS and MCA, the versatile BAT 115 battery tester tests 6 V and 12 V batteries from 40 - 2000 CCA, including lead-acid, EFB, Gel and AGM (flat and spiral) using a micro-load test for proven accurate results while also offering the ability to test 12 V and 24 V charging systems with a diode/ripple test.
- Micro-load test procedure: Produces fast and reliable measurement results
- Large LCD screen: For clear, legible results which can be referenced quickly
- EN, EN2, DIN, SAE, IEC, JIS and MCA testing norms: For versatile testing of 6 V and 12 V batteries, and the 12 V and 24 V starter charging systems
- Guided menus in 25 languages with 3-button operation: Easy and intuitive to use
- Integrated printer presenting state of health and state of charge percentage: Provides the customer with clear and easy to understand graphical printouts for their records
- 1.8 meter testing cable: For excellent coverage around the vehicle in the workshop
- Only 1100 g with robust housing: Provides easy handling and durability for daily use
- Detachable test clamps: For service or replacement
- Supports testing of starting and charging systems
- Battery nominal voltage: 6 V / 12 V
- Application: Passenger car, light commercial vehicle, motorcycle, marine
- Battery types: Lead-acid, EFB, Gel & AGM (flat and spiral)
- Test standards: EN, EN2, DIN, SAE, IEC, JIS, MCA
- Battery size (in acc. with CCA): 40 – 2000 A
- Printer: Integrated thermal printer
- Starting/charging system test 12 V / 24 V
- Number of Menu languages: 25 languages
- Dimensions (W x H x D): approx. 250 x 130 x 60mm
- Weight approx.: 1100 g
- Operating temperature: 0 – 40 degree(C)
ONLY
£571.09
£571.09
Part number: 1684465914
Important compatibility info
| Title | Bosch OBD Interface Module |
Additional Information
The OBD Interface Module is an optional add on to enhance your ability to perform TPMS readings using the TPA 300. Allowing the user to write sensor values into the ECU of a vehicle with increased efficiency. The module also simplifies workflow particularly when working with Asian OEM's.
- Kit with LAN cable
- Writes sensor values into ECU of vehicle as integrated part of the process
- Writing sensor values can also be done using the ESI[tronic] – but the dongle is faster, since there is no typing required
- OBD Module simplifies the workflow significantly when it is needed (mainly Asian OEMs such as Toyota, Hyundai, Nissan), reduces manual data entry of long sensor codes
ONLY
£308.38
£308.38
Part number: GID02020EN
Important compatibility info
| Title | Professional A/C Charging Gun with Gauge |
Additional Information
- Heavy duty charging gun with gauge
- Attaches to R-134a can
- One-hand control unit - squeeze trigger to fill and release to measure
- Allows for accurate measuring and charging of R-134a systems
- Made from heavy-duty aluminium
ONLY
£67.90
£67.90
Part number: 501780M
Important compatibility info
ONLY
£20.67
£20.67
Part number: 30520
Important compatibility info
| Title | Jump Lead Clips - 600A - Pair |
Additional Information
- Heavy-duty booster cable handles
- Fully insulated handles
- Rated up to 600 Amp
- Suitable for up to 35mm2 cable
ONLY
£18.50
£18.50
Part number: YCXLEDM6
Important compatibility info
ONLY
£15.92
£15.92
Part number: 1928403736
Important compatibility info
| Function | Plug Housing |
| Type | Plug Housing |
ONLY
£5.78
£5.78
Part number: 1928403453
Important compatibility info
| Function | Plug Sleeve, ignition system |
| Type | Plug Sleeve, ignition system |
ONLY
£4.93
£4.93
